Nominal
pressure, PN – up to 1,6; 2,5; 4,0 Mpa
(16; 25; 40 kgf/cm2).
Nominal
bore -10; 15; 20; 25; 32; 40; 50 mm.
Connection – flanged, union, welding joints.
Working medium: water, steam.
Temperature of working medium up to
350oC.
Direction of working medium -
bilaterial.
Sealing materials - metal-to-metal.
Tightness
- class 'C' according to the Russian State Standart.
Body
material - carbon steel.
Working position of the valve - any.
|
Drawing symbol |
Table of
figures |
PN, MPa
(kgf/cm2) |
Dimensions,
mm |
Pipeline
connection
|
Weight,
kg |
|
L |
b |
d |
D |
|
BPA39003-010 |
10s8br |
1,6 (16) |
156 |
12 |
8 |
15 |
flanged |
2,6 |
|
-01 |
10s8br1 |
94 |
-- |
union |
1,5 |
|
-02 |
10s8br2 |
104 |
welding |
1,4 |
|
-03 |
10s9br |
2,5 (25) |
160 |
14 |
flanged |
2,7 |
|
-04 |
10s9br1 |
94 |
-- |
union |
1,5 |
|
-05 |
10s9br2 |
104 |
welding |
1,4 |
|
-06 |
10s10br |
4,0 (40) |
176 |
14 |
flanged |
2,75 |
|
-07 |
10s10br1 |
94 |
- |
union |
1,5 |
|
-08 |
10s10br2 |
104 |
welding |
1,4 |
|
БПА39003-015 |
10s8br |
1,6 (16) |
156 |
12 |
12 |
19 |
flanged |
3,0 |
|
-01 |
10s8br1 |
104 |
-- |
union |
1,7 |
|
-02 |
10s8br2 |
welding |
1,6 |
|
-03 |
10s9br |
2,5 (25) |
160 |
14 |
flanged |
3,0 |
|
-04 |
10s9br1 |
94 |
-- |
union |
1,7 |
|
-05 |
10s9br2 |
104 |
welding |
1,6 |
|
-06 |
10s10br |
4,0 (40) |
176 |
14 |
flanged |
3,2 |
|
-07 |
10s10br1 |
94 |
- |
union |
1,7 |
|
-08 |
10s10br2 |
104 |
welding |
1,6 |
|
БПА39003-020 |
10s8br |
1,6 (16) |
165 |
14 |
18 |
26 |
flanged |
4,0 |
|
-01 |
10s8br1 |
110 |
-- |
union |
2,1 |
|
-02 |
10s8br2 |
welding |
2,0 |
|
-03 |
10s9br |
2,5 (25) |
170 |
14 |
flanged |
4,0 |
|
-04 |
10s9br1 |
110 |
-- |
union |
2,1 |
|
-05 |
10s9br2 |
welding |
2,0 |
|
-06 |
10s10br |
4,0 (40) |
190 |
14 |
flanged |
4,0 |
|
-07 |
10s10br1 |
110 |
- |
union |
2,1 |
|
-08 |
10s10br2 |
welding |
2,0 |
|
БПА39003-025 |
10s8br |
1,6 (16) |
168 |
16 |
25 |
34 |
flanged |
5,25 |
|
-01 |
10s8br1 |
110 |
-- |
union |
2,7 |
|
-02 |
10s8br2 |
welding |
2,7 |
|
-03 |
10s9br |
2,5 (25) |
168 |
16 |
flanged |
5,1 |
|
-04 |
10s9br1 |
110 |
-- |
union |
2,7 |
|
-05 |
10s9br2 |
welding |
2,7 |
|
-06 |
10s10br |
4,0 (40) |
194 |
14 |
flanged |
5,1 |
|
-07 |
10s10br1 |
110 |
- |
union |
2,7 |
|
-08 |
10s10br2 |
welding |
2,7 |
|
БПА39003-032 |
10s8br |
1,6 (16) |
180 |
16 |
32 |
40 |
flanged |
6,1 |
|
-01 |
10s8br1 |
130 |
-- |
union |
2,6 |
|
-02 |
10s8br2 |
welding |
2,6 |
|
-03 |
10s9br |
2,5 (25) |
184 |
18 |
flanged |
6,4 |
|
-04 |
10s9br1 |
130 |
-- |
union |
2,6 |
|
-05 |
10s9br2 |
welding |
2,6 |
|
-06 |
10s10br |
4,0 (40) |
235 |
16 |
flanged |
6,3 |
|
-07 |
10s10br1 |
130 |
- |
union |
2,6 |
|
-08 |
10s10br2 |
welding |
2,6 |
|
БПА39003-040 |
10s8br |
1,6 (16) |
184 |
17 |
38 |
48 |
flanged |
7,1 |
|
-01 |
10s8br1 |
130 |
-- |
union |
3,0 |
|
-02 |
10s8br2 |
welding |
2,6 |
|
-03 |
10s9br |
2,5 (25) |
192 |
19 |
flanged |
7,3 |
|
-04 |
10s9br1 |
130 |
-- |
union |
3,0 |
|
-05 |
10s9br2 |
welding |
2,6 |
|
-06 |
10s10br |
4,0 (40) |
240 |
16 |
flanged |
7,1 |
|
-07 |
10s10br1 |
130 |
- |
union |
3,0 |
|
-08 |
10s10br2 |
welding |
2,6 |
|
БПА39003-050 |
10s8br |
1,6 (16) |
260 |
19 |
50 |
60 |
flanged |
14,5 |
|
-01 |
10s8br1 |
160 |
-- |
union |
9,0 |
|
-02 |
10s8br2 |
welding |
8,8 |
|
-03 |
10s9br |
2,5 (25) |
265 |
21 |
flanged |
14,8 |
|
-04 |
10s9br1 |
160 |
-- |
union |
9,0 |
|
-05 |
10s9br2 |
welding |
8,6 |
|
-06 |
10s10br |
4,0 (40) |
280 |
17 |
flanged |
14,3 |
|
-07 |
10s10br1 |
160 |
- |
union |
9,0 |
|
-08 |
10s10br2 |
welding |
8,6 |
|
