Nominal Bore, DN mm |
Dimensions, mm |
n. pc |
Weight, kg |
|
D |
L |
D1 |
D2 |
D3 |
d |
|
50 |
50 |
140 |
40 |
160 |
125 |
18 |
4 |
8,7 |
|
80 |
80 |
170 |
65 |
195 |
160 |
18 |
4 |
11,9 |
|
100 |
100 |
200 |
85 |
215 |
180 |
18 |
8 |
18 |
Nominal pressure, PN – up to 1,6 Mpa
(16 kgf/cm2).
Connection – flanges.
Working medium: liquid and gaseous, not aggressive and
aggressive media.
Temperature of working medium up to 200oC.
Direction of working medium - by the arrow at the body.
Sealing materials - fluoroplast.
Working position - any.
Material of the main parts - carbon steel - for not
aggressive media, stainless steel - for aggressive media. |
